Submersible slurry pump
ump Size: 4-20inch
Capacity Range：24-2500 m3/h
Head Range: 13-78 m
Speed Range:980/1460
Power Range: 7.5-315kw
Submersible slurry pump is a motor and pump coaxial immersed in the medium. The wet parts are made of high chrome wear-resistant alloy, with good wear resistance and large channel. It is suitable for conveying sludge, slurry, coal slurry, sand and stone containing large solid particles and other media.
The unique double-bladed impeller structure, in addition to the main impeller, is also equipped with a stirring impeller at the bottom, which can mix the sediment deposited at the bottom into turbulence and then extract it. The motor is protected by mechanical seal to effectively prevent high-pressure water and impurities from entering the inner cavity of the motor.
submersible sand pump
Hydraulic submersible sand pump
1. The pump bottom is arranged with the agitator, and the bilateral and multilateral separate agitator can be arranged, which can prevent pump blockage by the bulky fixed substance, so as to fully mix the solid with liquid, and facilitate handling.
2. The pump casing, impeller, suction plate, stirring impeller and other wet parts are made of high chrome alloy. Other materials can be customized.
3. Durable, main wear parts made from anti-wear 27% chrome alloy material, hardness can be over 60HRC;
4. The unique sealing device is adopted, so as to avoid frequent replacement of mechanical seal,and improve the working efficiency.
5. Various driven type, you can choose power by hydraulic or electric power;
6. Electric submersible sand pump optional water jet system and extra stirs to increase sand production.
7. Hydraulic submersible sand pump can be used with excavators and can be optionally equipped with a hydraulic power station to solve the power inconvenience problem during construction in remote areas.
♦ Rivers, lakes, sea, reservoirs, port dredging silt. | ♦ Pumping sand beneficiation: Select iron sand pumping, pumping sand gold, rare earths. |
♦ Sewage treatment plant settling ponds cleanup. | ♦ Municipal pipelines, storm water pumping station, hydroelectric sediment cleanup. |
♦ Construction (sinking bridge construction, etc.) discharge of sediment, mud. | ♦ Steel plant blast furnace slag, slag, pumping iron oxide delivery. |
| ♦ Concentrator tailings, slag, slurry transportation. | ♦ Coal cinder, coal, coal slurry cleanup. |
| ♦ Power plant fly ash, coal, coal slurry transportation. | ♦ All kinds of diamond sand, quartz sand, slag solid particles. |
Related Products
Yes, we are a manufacturer of slurry pump in China since 2000.
Yes, OEM/ODM are available.
T/T Bank Wiring, L/C, Western Union, Moneygram, Paypal.
By sea, air, railway.
Slurry pumps typically have a volute casing which is rubber lined, as well as a rubber lined impeller in order to minimise wear to internal metal parts. As slurries can be highly abrasive, and travel at high velocity the rubber is used as a sacrificial liner.
As the rubber wears, the tolerances within the unit become larger meaning the pump becomes less efficient. Designs have front and rear adjustment to reduce internal clearances to improve unit efficiency as they wear.
